Clevises Pin (LL Series)

Quantity:

Product Description

Clevises Pin (LL Series).pdf


ISO

链号ISO

Chain No.

孔距Width between

holes

X

min

mm

销轴长度Pin length

L

max

mm

销轴直径Pin diameter


d2 max

mm

孔径Hole diameter


D

mm

LL0822

8.1

14.5


4.45




1.6



LL0844

14.5

20.9

LL0866

20.8

27.2

LL1022

8.6

15.0


5.08




1.6



LL1044

15.4

21.8

LL1066

22.1

28.5

LL1222

10.0

18.0


5.72




2.0



LL1244

17.8

25.8

LL1266

25.6

33.6

LL1622

16.5

29.3


8.28




3.2



LL1644

29.5

42.3

LL1666

42.5

55.3

LL2022

19.1

31.9


10.19




3.2



LL2044

34.1

46.9

LL2066

49.1

61.9

LL2422

26.6

42.6


14.63




4.0



LL2444

47.6

63.6

LL2466

68.6

84.6

LL2822

32.9

48.9


15.90




4.0



LL2844

58.9

74.9

LL2866

84.9

100.9

LL3222

33.0

53.0


17.81




5.0



LL3244

59.0

79.0

LL3266

85.0

105.0

LL4022

42.1

67.3


22.89




6.3



LL4044

75.3

100.5

LL4066

108.5

133.7

LL4822

52.4

77.6


29.24




6.3



LL4844

93.8

119.0

LL4866

135.2

160.4



Chain No.

孔距Width between

holes

X

min

mm

销轴长度Pin length

L

max

mm

销轴直径Pin diameter


d2 max

mm

孔径Hole diameter


D

mm

LL2466(DG)

67.7

85.0

14.63

5.0

LL2844(DGF1)

66.0

83.4

15.90


5.0


LL2866(DG)

73.6

90.8

LL3266(DGF1)

85.7

104.0


17.81




5.0

LL3288(DGF2)

117.0

134.0

5.0

LL3244F2(DG)

73.2

90.2

4.7

LL3266F6(DG)

85.7

104.0

5.0

LL4066(DG)

104.3

125.3

22.89


6.3

LL4088F2(DG)

169.0

195.0

6.0
