Product Description
The gearbox has a compact structure and can be controlled by a variety of control methods. The operation is light and sensitive, and it can be operated from a distance, which is convenient for driving and machine integration.
The advanced design makes the connection of the gearbox very soft, easy to maintain, more durable, and has the characteristics of large transmission power, small size and light weight.
The toothed elastic input coupling and connection cover can be matched with various flywheels and flywheel shells to connect with the host, easy installation and beautiful appearance
With excellent deceleration effect and strong bearing propeller thrust
Professional gearbox specialists and after-sales service, spare parts directly available from stock.
Parameter
| Gearbox Model: | 6 |
| Input Speed: | 1000-2100 RPM |
| Power: | 8.4 kW @ 2100 RPM |
| Center Distance: | 124 mm |
| Trans.Capacity: | 0.004 kW / RPM |
| Reduction Ratio: | 2.52 3.05 3.50 |
| Rated Thrust: | 1.8 kN |
| Dimension: | 350 mm * 316 mm * 482 mm |
| Net Weight: | 58 kg |
