OIC-EB-900 Sliding Door Motor

Availability:
Quantity:

Product Description

OIC-EB-900

Supply Voltage(V) AC230/120V
Motor Power(W) 900W
Torque 45Nm
Maximum Weight Of Gate 2000kg
Motor Rotation Speed(Rated) 1400r/min
Gate Speed 12M/Minute
Limit Switch Spring switch/magnetic switch
Noise ≤56dB
Operating Environment Temperature  -45℃~65℃
Certificates   CCC, CE



Technical Data Sheet

With exquisite appearance,the main body of the high quality ABS and Aluminium through spray painting
The motor is powerful,starts smoothly,has big torque and low noise,and is smooth and reliable when operating.
With built-in thermal protector(the motor will automatically cut off power supply for protection when the motor heat up to rated temperature).
The circuit of the Photocell has the functions of electronic infrared ray collision prevention and electronic reversion when meeting obstacle so as to ensure pedestrians' safety.
Our motor is self-locking. If there is short of electric power, you only need to turn the key clockwise 90 degree, then pull the black bar about 60-90degree(more than 45 degree), then the door can move by hand. No need backup battery.
Installation is simple,easy maintenance.
