Product Description
Stock Bore Double Pitch Sprockets is a standard sprocket product used in the ANSI market, with key features including: these sprockets are suitable for ANSI standard inch sizes such as 2040, 2050, 2060, 2080, etc. Specific models such as 2042, 2052, 2062, and 2082 are also available. These sprockets are typically made of high-quality steel, such as C45 steel, ensuring their durability and strength.
These sprockets are mainly used in conveyor systems and are particularly suitable for applications that require long-term operation due to their lower torque requirements and longer service life. Some models such as 2060B11, 2082B8, and 2082B25 are available in stock and can be customized according to demand.
These sprockets have good tooth strength and simple installation methods, making them suitable for various design solutions.In summary, Stock Bore Double Pitch Sprockets is a high-quality standard sprocket product suitable for various industrial applications, capable of meeting the needs of different customers and ensuring long-term stable operation.
Parameter
2040-C2040
| Z | O.D | P.C.D | Bore | Hub | ||
| D | Max | BD | BL | |||
| 11 12 13 14 15 | 2.000 2.170 2.330 2.490 2.650 | 1.852 2.000 2.152 2.305 2.458 | 1/2 1/2 1/2 1/2 5/8 | 13/16 13/16 21/32 11/32 17/32 | 13/8 19/16 19/16 111/16 123/32 | 7/8 7/8 7/8 7/8 7/8 |
| 16 17 18 19 20 | 2.810 2.980 3.140 3.300 3.460 | 2.613 2.768 2.924 3.080 3.236 | 5/8 5/8 5/8 5/8 5/8 | 19/32 15/16 115/32 15/8 13/4 | 17/8 23/64 27/32 23/8 235/64 | 7/8 1 1 1 1 |
| 21 22 23 24 25 | 3.620 3.780 3.940 4.100 4.260 | 3.392 3.549 3.706 3.864 4.021 | 5/8 5/8 5/8 5/8 5/8 | 125/32 17/8 2 21/4 21/4 | 245/64 27/8 3 31/4 31/4 | 1 1 1 1 1 |
| 26 28 30 | 4.420 4.740 5.060 | 4.179 4.494 4.810 | 5/8 5/8 5/8 | 21/4 21/4 21/4 | 31/4 31/4 31/4 | 1 1 1 |
2050-C2050
| Z | O.D | P.C.D | Bore | Hub | ||
| D | Max | BD | BL | |||
| 11 12 13 14 15 | 2.500 2.710 2.910 3.110 3.320 | 2.315 2.500 2.690 2.881 3.073 | 5/8 5/8 5/8 5/8 5/8 | 13/16 1 17/32 19/32 113/32 | 13/4 163/64 123/32 115/16 25/32 | 1 1 1 1 1 |
| 16 17 18 19 20 | 3.520 3.720 3.920 4.120 4.320 | 3.266 3.460 3.655 3.850 4.045 | 5/8 5/8 5/8 5/8 3/4 | 119/32 13/4 125/32 131/32 2 | 223/64 29/16 225/32 263/64 3 | 1 1 1 1 1 |
| 21 22 23 24 25 | 4.520 4.720 4.920 5.120 5.320 | 4.241 4.437 4.633 4.830 5.026 | 3/4 3/4 3/4 3/4 3/4 | 2 2 2 2 2 | 3 3 3 3 3 | 1 1 1 11/4 11/4 |
| 26 28 30 | 5.520 5.920 6.320 | 5.223 5.617 6.012 | 3/4 3/4 3/4 | 2 2 21/4 | 3 3 31/4 | 11/4 11/4 11/4 |
2060-C2060
| Z | O.D | P.C.D | Bore | Hub | ||
| D | Max | BD | BL | |||
| 11 12 13 14 15 | 3.000 3.250 3.490 3.740 3.980 | 2.773 3.000 3.228 3.457 3.688 | 3/4 3/4 3/4 3/4 3/4 | 1 11/4 15/16 19/16 13/4 | 21/16 23/8 25/64 221/64 219/32 | 11/4 11/4 11/4 11/4 11/4 |
| 16 17 18 19 20 | 4.220 4.460 4.700 4.940 5.190 | 3.920 4.152 4.386 4.620 4.854 | 3/4 3/4 3/4 3/4 3/4 | 127/32 23/32 29/32 211/32 29/16 | 227/32 33/32 311/32 31/2 37/8 | 11/4 11/4 11/4 11/4 11/4 |
| 21 22 23 24 25 | 5.430 5.670 5.910 6.150 6.390 | 5.089 5.324 5.560 5.796 6.032 | 3/4 3/4 3/4 3/4 3/4 | 23/4 23/4 23/4 23/4 23/4 | 4 4 4 4 4 | 11/4 11/4 11/4 11/4 11/4 |
| 26 28 30 | 6.630 7.110 7.590 | 6.268 6.741 7.215 | 3/4 3/4 3/4 | 23/4 23/4 23/4 | 4 4 4 | 11/4 11/4 11/4 |
2080-C2080
| Z | O.D | P.C.D | Bore | Hub | ||
| D | Max | BD | BL | |||
| 11 12 13 14 15 | 4.010 4.330 4.660 4.980 5.300 | 3.694 4.000 4.304 4.610 4.917 | 1 1 1 1 1 | 11/2 111/16 125/32 21/8 29/32 | 213/16 31/8 225/32 31/8 329/64 | 15/8 15/8 11/2 11/2 11/2 |
| 16 17 18 19 20 | 5.630 5.950 6.270 6.590 6.910 | 5.226 5.536 5.848 6.160 6.472 | 1 1 1 1 1 | 217/32 23/4 23/4 23/4 23/4 | 351/64 4 41/4 41/4 41/4 | 11/2 11/2 11/2 11/2 11/2 |
| 21 22 23 24 25 | 7.230 7.560 7.880 8.200 8.520 | 6.785 7.099 7.413 7.727 8.042 | 1 1 1 1 1 | 23/4 23/4 23/4 23/4 23/4 | 41/4 41/4 41/4 41/4 41/4 | 13/4 13/4 13/4 13/4 13/4 |
| 26 28 30 | 8.840 9.480 10.110 | 8.357 8.988 9.620 | 11/4 13/16 13/16 | 31/4 31/4 31/4 | 43/4 43/4 43/4 | 2 2 2 |
