K Standard Sprockets A Type K100A

Quantity:



Inquire Add to Basket

Product Description

Technical Data Sheet

"WE SOLVE YOUR PROBLEMS
AND SELL SOLUTIONS"
* BIG INVENTORY. * REASONABLE PRICES. * DELIVERY ON TIME.

* AVAILABLE MADE-TO-ORDER SPROCKET.

Chain Pitch	(P)	31.75	mm (1-1/4 inch)
Inner Width	(W)	19.05	mm
Bush Dia.	(Dr)	19.05	mm
Tooth Width	(T)	17.6	mm

(Dimension : mm)


Sprocket No.		Outside Dia. Do	Pitch Dia. Dp	Bore Dia. d		Weight (kg)	Material	Teeth
Type	Teeth	Outside Dia. Do	Pitch Dia. Dp	Stock Bore	Min.	Weight (kg)	Material	Teeth
K100A	10	117	102.74	20	22	1.10	Mild Steel	10
	11	127	112.70	20	22	1.30		11
	12	138	122.67	20	22	1.60		12
	13	148	132.67	20	22	1.90		13
	14	158	142.68	20	22	2.15		14
	15	168	152.71	20	22	2.50		15
	16	179	162.74	20	22	2.83		16
	17	189	172.79	20	22	3.20		17
	18	199	182.84	20	22	3.60		18
	19	209	192.90	20	22	4.00		19
	20	220	202.96	20	22	4.40		20
	21	230	213.03	20	22	4.90		21
	22	240	223.10	20	22	5.35		22
	23	250	233.17	20	22	5.80		23
	24	260	243.25	20	22	6.40		24
	25	270	253.32	20	22	6.90		25
	26	281	263.40	20	22	7.50		26
	27	291	273.49	20	22	8.10		27
	28	301	283.57	20	22	8.70		28
	29	311	293.66	20	22	9.30		29
	30	321	303.75	26	28	10.00		30
	31	331	313.83	26	28	10.63		31
	32	341	323.92	26	28	11.35		32
	33	352	334.01	26	28	12.00		33
	34	362	344.11	26	28	12.80		34
	35	372	354.20	26	28	13.50		35
	36	382	364.29	26	28	14.40		36
	37	392	374.38	26	28	15.10		37
	38	402	384.48	26	28	16.00		38
	39	412	394.57	26	28	16.80		39
	40	422	404.67	26	28	17.70		40
	41	433	414.77	26	28	18.60		41
	42	443	424.86	26	28	19.50		42
	43	453	434.96	26	28	20.50		43
	44	463	445.06	26	28	21.45		44
	45	473	455.16	26	28	22.40		45
	46	483	465.25	26	28	23.40		46
	48	503	485.45	26	28	25.50		48
	50	524	505.65	26	28	27.70		50
	52	544	525.85	26	28	29.90		52
	54	564	546.05	26	28	32.30		54
	55	574	556.15	26	28	33.00		55
	60	625	606.66	26	28	39.90		60
	65	675	657.17	26	28	46.80		65
	70	726	707.68	26	28	54.30		70
	75	777	758.20	26	28	62.30		75
	80	827	808.71	26	28	70.90		80
	90	928	909.75	26	28	89.58		90

China Sprocket manufacturer, chinese Sprocket supplier, produce: chain sprocket,taper lock sprockets,Singapore sprockets,casting sprockets,finished sprockets,plate wheels,chains wheels. We can produce as per customer's drawing or sample. Please feel free to send us your detail enquiries. E-mail: oceanindustry@vip.163.com
