| CHAIN TECHNICAL DATA | | Chain Pitch | 11/4 | | Inner Width | 0.750 | | Roller Dia. | 0.750 | | Tooth Width (T) | 0.692 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 8 | 3.770 | 1 | 1 1/4 | 2 7/16* | 1 7/8 | 2.3 | | 9 | 4.180 | 1 | 1 5/8 | 2 13/16* | 1 7/8 | 3.2 | | 10 | 4.600 | 1 | 1 7/8 | 3 1/4* | 1 7/8 | 4.1 | | 11 | 5.010 | 1 | 2 1/4 | 3 9/16* | 1 7/8 | 5.3 | | 12 | 5.420 | 1 | 2 1/4 | 4* | 1 7/8 | 6.4 | | 13 | 5.820 | 1 | 2 3/8 | 3 7/8 | 1 5/8 | 6.6 | | 14 | 6.230 | 1 1/4 | 2 3/4 | 4 3/16 | 1 5/8 | 7.4 | | 15 | 6.630 | 1 1/4 | 3 | 4 1/2 | 1 3/4 | 9.2 | | 16 | 7.030 | 1 5/16 | 3 | 4 1/2 | 1 3/4 | 9.9 | | 17 | 7.440 | 1 5/16 | 3 | 4 1/2 | 1 3/4 | 10.8 | | 18 | 7.840 | 1 5/16 | 3 | 4 1/2 | 1 3/4 | 11.5 | | 19 | 8.240 | 1 5/16 | 3 | 4 1/2 | 2 | 13.1 | | 20 | 8.640 | 1 5/16 | 3 | 4 1/2 | 2 | 14.2 | | 21 | 9.040 | 1 5/16 | 3 | 4 1/2 | 2 | 15.3 | | 22 | 9.440 | 1 5/16 | 3 | 4 1/2 | 2 | 16.1 | | 23 | 9.840 | 1 1/4 | 3 | 4 1/2 | 2 | 17.2 | | 24 | 10.250 | 1 1/4 | 3 | 4 1/2 | 2 | 19.2 | | 25 | 10.650 | 1 1/4 | 3 | 4 1/2 | 2 | 19.5 | | 26 | 11.050 | 1 1/4 | 3 5/16 | 5 | 2 | 21.7 | | 27 | 11.440 | 1 1/4 | 3 5/16 | 5 | 2 | 23.0 | | 28 | 11.840 | 1 1/4 | 3 5/16 | 5 | 2 | 24.4 | | 29 | 12.240 | 1 1/4 | 3 5/16 | 5 | 2 | 25.0 | | 30 | 12.640 | 1 1/4 | 3 5/16 | 5 | 2 | 26.9 | | 32 | 13.440 | 1 1/4 | 3 5/16 | 5 | 2 | 29.8 | | 35 | 14.640 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 36.9 | | 36 | 15.040 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 38.6 | | 38 | 15.840 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 41.5 | | 39 | 16.230 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 43.6 | | 40 | 16.630 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 46.9 | | 42 | 17.430 | 1 1/4 | 3 5/16 | 5 | 2 1/2 | 50.4 | | 45 | 18.630 | 1 1/2 | 3 5/16 | 5 | 2 1/2 | 54.0 | | 48 | 19.820 | 1 1/2 | 4 | 6 | 2 1/2 | 66.0
| |
