| CHAIN TECHNICAL DATA | | Chain Pitch | 11/2 | | Inner Width | 1.000 | | Roller Dia. | 0.875 | | Tooth Width (T) | 0.924 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 9 | 5.020 | 1 3/8 | 1 13/16 | 3 3/8* | 2 1/4 | 5.3 | | 10 | 5.520 | 1 3/8 | 2 1/4 | 3 3/4* | 2 1/4 | 7.1 | | 11 | 6.010 | 1 3/8 | 2 3/8 | 3 9/16 | 2 1/8 | 7.6 | | 12 | 6.500 | 1 3/8 | 2 3/4 | 4 1/8 | 2 1/8 | 9.9 | | 13 | 6.990 | 1 3/8 | 3 | 4 9/16 | 2 1/4 | 12.4 | | 14 | 7.470 | 1 3/8 | 3 1/4 | 4 3/4 | 2 1/4 | 14.4 | | 15 | 7.960 | 1 1/4 | 3 1/4 | 4 3/4 | 2 3/8 | 16.7 | | 16 | 8.440 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 19.9 | | 17 | 8.920 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 20.8 | | 18 | 9.410 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 22.2 | | 19 | 9.890 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 24.8 | | 20 | 10.370 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 25.8 | | 21 | 10.850 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 26.7 | | 22 | 11.330 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 28.2 | | 23 | 11.810 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 30.3 | | 24 | 12.290 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 32.1 | | 25 | 12.770 | 1 1/4 | 3 1/2 | 5 1/4 | 2 3/8 | 34.6 | | 26 | 13.250 | 1 1/2 | 4 | 6 | 2 1/2 | 40.0 | | 28 | 14.210 | 1 1/2 | 4 | 6 | 2 1/2 | 44.9 | | 30 | 15.170 | 1 1/2 | 4 | 6 | 2 1/2 | 50.2 | | 32 | 16.130 | 1 1/2 | 4 | 6 | 2 1/2 | 56.0 | | 35 | 17.570 | 1 1/2 | 4 | 6 | 2 1/2 | 62.4 | | 36 | 18.050 | 1 1/2 | 4 | 6 | 2 1/2 | 66.4
| |
