| CHAIN TECHNICAL DATA | | Chain Pitch | 2 | | Inner Width | 1.250 | | Roller Dia. | 1.125 | | Tooth Width (T) | 1.156 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension: inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec
Max. | Dia.
BD | Length
Thru
BL | | 8 | 6.030 | 1 1/2 | 1 7/8 | 3 1/4 | 2 1/4 | 8.0 | | 9 | 6.700 | 1 1/2 | 2 1/8 | 3 5/8 | 2 1/4 | 10.0 | | 10 | 7.360 | 1 1/2 | 2 3/4 | 4 1/8 | 2 1/4 | 12.0 | | 11 | 8.010 | 1 1/2 | 3 1/4 | 4 3/4 | 2 1/2 | 17.0 | | 12 | 8.660 | 1 1/2 | 3 3/4 | 5 1/2 | 2 1/2 | 21.0 | | 13 | 9.310 | 1 1/2 | 4 | 6 | 2 3/4 | 28.0 | | 14 | 9.960 | 1 1/2 | 4 1/2 | 6 1/2 | 2 3/4 | 32.0 | | 15 | 10.610 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 37.0 | | 16 | 11.260 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 41.0 | | 17 | 11.900 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 45.0 | | 18 | 12.540 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 48.0 | | 19 | 13.190 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 52.0 | | 20 | 13.830 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 56.0 | | 21 | 14.470 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 59.0 | | 22 | 15.110 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 65.0 | | 23 | 15.750 | 1 1/2 | 5 1/4 | 7 | 2 3/4 | 68.0 | | 24 | 16.390 | 1 1/2 | 5 1/4 | 7 | 3 | 77.0 | | 25 | 17.030 | 1 1/2 | 5 1/4 | 7 | 3 | 81.0 | | 26 | 17.670 | 1 1/2 | 5 1/4 | 7 | 3 | 86.0 | | 27 | 18.310 | 1 1/2 | 5 1/4 | 7 | 3 | 91.0 | | 28 | 18.950 | 1 1/2 | 5 1/4 | 7 | 3 | 98.0 | | 30 | 20.230 | 1 1/2 | 5 1/4 | 7 | 3 | 108
| |
