| CHAIN TECHNICAL DATA | | Chain Pitch | 21/2 | | Inner Width | 1.500 | | Roller Dia. | 1.562 | | Tooth Width (T) | 1.389 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 10 | 9.200 | 1 1/2 | 3 3/4 | 5 1/2 | 3 | 26 | | 11 | 10.020 | 1 1/2 | 4 | 6 | 3 | 33 | | 12 | 10.830 | 1 1/2 | 4 1/2 | 6 1/2 | 3 | 37 | | 13 | 11.640 | 1 1/2 | 5 1/4 | 7 | 3 | 46 | | 14 | 12.460 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 59 | | 15 | 13.260 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 64 | | 16 | 14.070 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 72 | | 17 | 14.870 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 76 | | 18 | 15.680 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 84 | | 19 | 16.480 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 91 | | 20 | 17.290 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 98 | | 21 | 18.090 | 1 1/2 | 5 3/8 | 7 1/2 | 3 1/2 | 106 | | 22 | 18.890 | 1 1/2 | 5 3/4 | 8 1/2 | 4 | 131 | | 23 | 19.690 | 1 1/2 | 5 3/4 | 8 1/2 | 4 | 136 | | 24 | 20.490 | 1 1/2 | 5 3/4 | 8 1/2 | 4 | 142 | | 25 | 21.290 | 1 1/2 | 5 3/4 | 8 1/2 | 4 | 153
| |
