| CHAIN TECHNICAL DATA | | Chain Pitch | | | Inner Width | | | Roller Dia. | | | Tooth Width (T) | 1.738 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 10 | 11.030 | 1 1/2 | 4 1/2 | 6 1/2 | 3 3/8 | 49 | | 11 | 12.020 | 1 1/2 | 4 3/4 | 7 | 3 7/8 | 66 | | 12 | 13.000 | 1 1/2 | 5 3/8 | 7 1/2 | 3 7/8 | 72 | | 13 | 13.970 | 1 1/2 | 5 3/8 | 7 1/2 | 3 7/8 | 81 | | 14 | 14.940 | 1 1/2 | 5 3/8 | 7 1/2 | 3 7/8 | 88 | | 15 | 15.910 | 1 1/2 | 5 3/8 | 7 1/2 | 3 7/8 | 98 | | 16 | 16.880 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 120 | | 17 | 17.850 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 137 | | 18 | 18.810 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 142 | | 19 | 19.780 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 154 | | 20 | 20.740 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 169 | | 21 | 21.710 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 186 | | 25 | 25.550 | 1 1/2 | 5 1/2 | 8 | 4 1/8 | 254 | |
