| CHAIN TECHNICAL DATA | | Chain Pitch | 5/8 | | Inner Width | 0.375 | | Roller Dia. | 0.400 | | Tooth Width (T) | 0.343 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 8 | 1.880 | 5/8 | 5/8 | 1 1/8* | 1 | .25 | | 9 | 2.090 | 5/8 | 3/4 | 1 3/8* | 1 | .36 | | 10 | 2.300 | 5/8 | 7/8 | 1 9/16* | 1 | .48 | | 11 | 2.500 | 5/8 | 1 | 1 3/4* | 1 | .64 | | 12 | 2.710 | 5/8 | 1 1/4 | 1 63/64* | 1 | .83 | | 13 | 2.910 | 5/8 | 1 5/16 | 1 7/8 | 1 | .88 | | 14 | 3.110 | 5/8 | 1 7/16 | 2 1/8 | 1 | 1.13 | | 15 | 3.320 | 5/8 | 1 1/2 | 2 3/8 | 1 | 1.34 | | 16 | 3.520 | 5/8 | 1 3/4 | 2 1/2 | 1 | 1.51 | | 17 | 3.720 | 5/8 | 1 7/8 | 2 11/16 | 1 | 1.74 | | 18 | 3.920 | 5/8 | 1 7/8 | 2 7/8 | 1 | 2.00 | | 19 | 4.120 | 5/8 | 2 | 3 | 1 | 2.22 | | 20 | 4.320 | 3/4 | 2 | 3 | 1 | 2.28 | | 21 | 4.520 | 3/4 | 2 | 3 | 1 | 2.40 | | 22 | 4.720 | 3/4 | 2 | 3 | 1 | 2.56 | | 23 | 4.920 | 3/4 | 2 | 3 | 1 | 2.66 | | 24 | 5.120 | 3/4 | 2 | 3 | 1 1/4 | 3.30 | | 25 | 5.320 | 3/4 | 2 | 3 | 1 1/4 | 3.40 | | 26 | 5.520 | 3/4 | 2 | 3 | 1 1/4 | 3.44 | | 27 | 5.720 | 3/4 | 2 | 3 | 1 1/4 | 3.74 | | 28 | 5.920 | 3/4 | 2 | 3 | 1 1/4 | 3.80 | | 29 | 6.120 | 3/4 | 2 | 3 | 1 1/4 | 4.06 | | 30 | 6.320 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 4.56 | | 31 | 6.520 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 4.74 | | 32 | 6.720 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 4.96 | | 33 | 6.920 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 5.20 | | 34 | 7.120 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 5.14 | | 35 | 7.320 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 5.44 | | 36 | 7.520 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 5.64 | | 37 | 7.720 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 5.90 | | 38 | 7.920 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 6.08 | | 39 | 8.120 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 6.30 | | 40 | 8.320 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 6.50 | | 41 | 8.520 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 6.64 | | 42 | 8.720 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 6.96 | | 43 | 8.910 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 7.06 | | 44 | 9.110 | 3/4 | 2 1/4 | 3 1/4 | 1 1/4 | 7.58 | | 45 | 9.310 | 3/4 | 2 1/2 | 3 3/4 | 1 1/4 | 8.58 | | 46 | 9.510 | 3/4 | 2 1/2 | 3 3/4 | 1 1/4 | 8.22 | | 47 | 9.710 | 3/4 | 2 1/2 | 3 3/4 | 1 1/4 | 8.48 | | 48 | 9.910 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 9.28 | | 49 | 10.110 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 9.22 | | 50 | 10.310 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 9.88 | | 51 | 10.510 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 9.70 | | 52 | 10.710 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 10.24 | | 53 | 10.910 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 10.48 | | 54 | 11.110 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 11.00 | | 55 | 11.310 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 10.93 | | 56 | 11.500 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 11.50 | | 57 | 11.700 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 12.00 | | 58 | 11.900 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 11.82 | | 59 | 12.100 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 12.32 | | 60 | 12.300 | 1 | 2 1/2 | 3 3/4 | 1 1/4 | 13.00 | | 70 | 14.290 | 1 | 2 1/2 | 3 3/4 | 1 3/4 | 18.16 | | 72 | 14.690 | 1 | 2 1/2 | 3 3/4 | 1 3/4 | 19.48 | | 76 | 15.486 | 1 | 2 1/2 | 3 3/4 | 1 3/4 | 21.00 | | 80 | 16.280 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 24.74 | | 84 | 17.080 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 25.50 | | 95 | 19.270 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 32.00 | | 96 | 19.470 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 32.92 | | 112 | 22.650 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 42.00
| |
