| CHAIN TECHNICAL DATA | | Chain Pitch | 1 | | Inner Width | 0.625 | | Roller Dia. | 0.625 | | Tooth Width (T) | 0.575 | | "WE SOLVE YOUR PROBLEMS AND SELL SOLUTIONS" - BIG INVENTORY.
- REASONABLE PRICES.
- DELIVERY ON TIME.
- AVAILABLE MADE-TO-ORDER SPROCKET.
|
(Dimension : inch)
No.
Teeth | Outside
Diameter
Do | Bore (Inches) | Hub (Inches) | Weight
Lbs.
(App) | Stock
d | Rec.
Max. | Dia.
BD | Length
Thru
BL | | 8 | 3.010 | 1 | 1 | 1 15/16* | 1 5/8 | 1.4 | | 9 | 3.350 | 1 | 1 5/16 | 2 1/4* | 1 5/8 | 1.6 | | 10 | 3.680 | 1 | 1 1/2 | 2 9/16* | 1 5/8 | 2.2 | | 11 | 4.010 | 1 | 1 5/8 | 2 13/16* | 1 5/8 | 3.2 | | 12 | 4.330 | 1 | 1 7/8 | 3 1/8* | 1 5/8 | 3.4 | | 13 | 4.660 | 1 | 2 | 3 | 1 1/2 | 3.5 | | 14 | 4.980 | 1 | 2 1/4 | 3 1/4 | 1 1/2 | 4.1 | | 15 | 5.300 | 1 | 2 1/2 | 3 13/16 | 1 1/2 | 5.3 | | 16 | 5.630 | 1 | 2 3/4 | 4 | 1 1/2 | 5.9 | | 17 | 5.950 | 1 | 2 3/4 | 4 | 1 1/2 | 6.6 | | 18 | 6.270 | 1 | 2 3/4 | 4 1/4 | 1 1/2 | 7.3 | | 19 | 6.590 | 1 | 2 3/4 | 4 1/4 | 1 1/2 | 7.8 | | 20 | 6.910 | 1 | 2 3/4 | 4 1/4 | 1 1/2 | 8.4 | | 21 | 7.240 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 9.4 | | 22 | 7.560 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 10.0 | | 23 | 7.880 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 10.7 | | 24 | 8.200 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 11.3 | | 25 | 8.520 | 1 | 2 3/4 | 4 1/4 | 1 3/4 | 11.9 | | 26 | 8.840 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 14.3 | | 27 | 9.160 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 15.4 | | 28 | 9.480 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 16.0 | | 29 | 9.800 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 17.1 | | 30 | 10.110 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 17.4 | | 31 | 10.430 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 18.7 | | 32 | 10.750 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 19.5 | | 33 | 11.070 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 19.6 | | 34 | 11.390 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 21.3 | | 35 | 11.710 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 22.1 | | 36 | 12.030 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 23.1 | | 37 | 12.350 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 23.8 | | 38 | 12.670 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 24.7 | | 39 | 12.990 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 25.6 | | 40 | 13.310 | 1 3/16 | 3 1/4 | 4 3/4 | 2 | 26.7 | | 41 | 13.630 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 27.8 | | 42 | 13.940 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 28.7 | | 43 | 14.260 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 29.4 | | 44 | 14.580 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 29.9 | | 45 | 14.900 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 31.4 | | 46 | 15.220 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 33.1 | | 47 | 15.540 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 34.0 | | 48 | 15.860 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 35.5 | | 49 | 16.180 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 35.8 | | 50 | 16.500 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 37.3 | | 51 | 16.810 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 38.6 | | 52 | 17.130 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 39.4 | | 53 | 17.450 | 1 1/4 | 3 1/4 | 4 3/4 | 2 | 41.3 | | 54 | 17.770 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 44.7 | | 55 | 18.090 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 45.6 | | 56 | 18.410 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 47.5 | | 57 | 18.730 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 48.5 | | 58 | 19.040 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 50.5 | | 59 | 19.360 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 52.1 | | 60 | 19.680 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 54.5 | | 65 | 21.270 | 1 1/4 | 3 1/2 | 5 1/4 | 2 | 61.8
| |
